Short Circuit Protection

Over Current Protection

36100-1
36100-3
36100-2

Over Charge Protection

Over Discharge Protection

Technical Specifications

Specification

Nominal Voltage

38.4V

Nominal Capacity

100Ah

Nominal Energy

3840Wh

Standard Charge Current

0.2C(CC-CV)

Max. Charge Curent

1C

Charge Condition

0°C~45°C

Standard Discharge Current

0.5C

Max. Continuous Discharge Current

1C

Discharge Condition

-20°C~65°C

Size

520*268*220mm

Weight

38±1kg

Enclosure

ABS Case, IP67

Terminals/Interfaces

M8

Cycle Life

6000 cycles DoD80% 0.2C/0.5C

Cell Configuration

12S1P
