Short Circuit Protection

Over Current Protection

80500-2
80500-1
80500-3

Over Charge Protection

Over Discharge Protection

Technical Specifications

Specification

Nominal Voltage

80V

Nominal Capacity

600Ah

Nominal Energy

48000Wh

Standard Charge Current

0.2C(CC-CV)

Max. Charge Curent

200A

Charge Condition

@0℃~45℃

Standard Discharge Current

0.5C

Max. Continuous Discharge Current

300A

Discharge Condition

@-20~60℃

Size

800*500*400mm

Weight

320±5kg

Enclosure

Steel Case, IP65

Terminals/Interfaces

M8 Terminal

Cycle Life

6000 cycles DOD80% 0.2C/0.5C

Cell Configuration

25S2P
