Short Circuit Protection

Over Current Protection

12150-1
12150-2
12150-3

Over Charge Protection

Over Discharge Protection

Technical Specifications

7 Modules

Nominal Voltage

12.8V

Nominal Capacity

150Ah

Nominal Energy

1920Wh

Standard Charge Current

0.2C(CC-CV)

Max. Charge Curent

2C

Charge Condition

0°C~40°C

Standard Discharge Current

0.5C

Max. Continuous Discharge Current

2C

Discharge Condition

-20°C~55°C

Size

355*175*188mm

Weight

13.5±0.3kg

Enclosure

ABS Case, IP67

Terminals/Interfaces

M8

Cycle Life

6000 cycles DoD80% 0.2C/0.5C

Cell Configuration

4S3P

Force-H3
