Short Circuit Protection
Over Current Protection
Over Charge Protection
Over Discharge Protection
Technical Specifications
Specification
Nominal Voltage
12.8V
Nominal Capacity
100Ah
Nominal Energy
1280Wh
Standard Charge Current
0.2C(CC-CV)
Max. Charge Curent
1C
Charge Condition
0℃~45℃
Standard Discharge Current
0.5C
Max. Continuous Discharge Current
1C
Discharge Condition
-20℃~65℃
Size
307*169*208mm
Weight
11.5±1kg
Enclosure
ABS Case, IP67
Terminals/Interfaces
M8
Cycle Life
6000 cycles DoD80% 0.2C/0.5C
Cell Configuration
4S1P
