Short Circuit Protection

Over Current Protection

12200商业储能-2
12200商业储能
12200商业储能-3

Over Charge Protection

Over Discharge Protection

Technical Specifications

Specification

Nominal Voltage

25.6V

Nominal Capacity

200Ah

Nominal Energy

5120Wh+3KW Built-in Inverter

Standard Charge Current

0.2C(CC-CV)

Max. Charge Curent

100A

Charge Condition

@0℃~45℃

Standard Discharge Current

0.5C

Max. Continuous Discharge Current

200A

Discharge Condition

@-20~65℃

Size

400*420*280mm

Weight

95±3kg

Enclosure

Metal Case, IP54

Terminals/Interfaces

M8 Terminal

Cycle Life

6000 cycles DOD80% 0.2C/0.5C

Cell Configuration

8S1P

Force-H3
